Model | 3260 |
Dimension (WxDxH) | 2570 mm x 1360 mm x 1780 mm |
Weight | 1300 kg |
Facility | Power : AC 220, 50/60 Hz Single-Phase Maximum Power
Consumption : 6.0 KVA Max Controller Circuit : 3.0 KVA Max Heater Circuit : 3.0 KVA (Option) |
Compressed Air | Dry Air of 5.0 kg/cm2 (0.49 Mpa) or higher, constant supply |
Vacuum Source | Build-in Diaphragm Vacuum Pump: Pumping Volume : 100 L/min Ultimate Pressure : 100 Torr (-13.3 Kpa) Max. |
Applicable Device | Type : BGA series, µBGA, Pga, QFP series, CSP, BCC, QFN, Flip-Chip,
TSOP Outer dimensions: 4 mm x 4 mm to 45 mm x 45 mm Lead / Ball pitch : 0.4 mm / 0.5 mm and above |
Multiple Testing Layout | 6 sites (Pitch 400 mm) |
Index Time | 3.0 sec (excluding test communication time)/ One site cycle time : 3.5 Sec |
Ram Rate | 1/5000 pcs |
Applicable Tray | JEDEC and EIAJ |
Categories | 4 categories (6 categories for option) |
Contact Force | Max. 60 Kgf (accuracy ± 1kgf) by servo motor (80 Kgf for Option) |
Soak Hot Temperature (Option) | Operating Mode : Room Temperature / High Temperature Temperature
Range : 50℃ to 150℃ (Heat-up time: Within 30 min) Accuracy : Pre-heater Bu er ± 5℃, Contact Area ± 3℃ Cooling Head : 10℃ + 5℃ |
Temperature Control (Option) | Operating Mode : Room Temperature / Cold Temperature Temperature Range : room temperature ~ -55℃ Accuracy : Contact Area ± 3℃ |
Tri Temp Control (Option) | Temperature Range : -40℃ ~ 125℃ ± 2℃
(150℃ Option) or -55℃ ~ 135℃ ± 2℃ (150℃ Option) |
ATC Module (Option) | Temperature Range : Ambient ~ 135℃± 2℃ (150℃ Option) |
Unity PTC (Option) | Temperature Range : ~ 85 ℃ (up to 300W Heat Dissipation) |
Tester Interface | Standard : RS-232 Option : GPIB, USB and TTL |
Features | Universal kit design ECD function (Easy-edit communication define)
Two tray (Color tray) mode available Continuous fail retest function Real pick and place system Yield control (Average yield of socket) Yield monitor (Per contact head plug)
System Invention Patent No.: 190373 Process Invention Patent No.: 190377 |
Option | CCD camera for device orientation detection Socket sensor / Socket CCD RF Shielding Box : 55db for PCIe, 80~90db for PCI/USB/RS232 Rotator (90 degree) Fault Auto Correlation Test (FACT) Built in Continuity Test (BICT)PoP handling capacity |
